Simrad NSO evo3S MPU Only

Simrad NSO evo3S MPU Only

• Large-Screen Navigation System


• Multi-TouchSensible (with compatible display)


• Dual Independent Video Output


• Full HD Video


• Performance Module compatibility


• Cartography Choice


• Smaller, lighter design


• Quad-Core Processing Power


• Independent HDMI output ports allow different setups on each display


• 2 x Quad core processors


• Dedicated processor per monitor gives superior speed and chart draw performance


• Control both NSO evo3S MPU monitors direct from your Ipad or Android Tablet.


• Multi zoom touch gestures


• Naviconics Depth Highlight range


• Naviconics shallow water highlight


• AIS Sarts


• Fusion Link Audio Device Support


• Grib Weather


• Flir Camera integration


• GS25 Antenna Configuration

Casing
ABS Plastic

Operating Temp
-15°C to +55°C

water ingress
IPx2

Weight
1060g

dimensions (overall)
281mm (W) x 232mm (H) x 65.5mm (D)

Electrical

Operating voltage
9 - 31.2 V DC

Power consumption
45W (Max)

Low power standby mode
yes

Protection
reverse polarity and temporary over-voltage to 36V

Alarm output current
capable of driving 10A relay coil

Processor
iMX61 quad core

RAM
DDR3 1GB

Storage
8GB Flash

Conformity
CE, C-Tick, HDMI

Interfaces

ethernet
3 ports total - 1 & 2 are PoE (RJ45 socket)

NMEA 2000
1 port on rear (Micro-C male)

Video input
2 ports on rear (BNC female. NTCS or PAL format)

Video output
1024x768 (XGA 4:3), 1280x720 (HD 16:9),

USB
mass storage, keyboard and mouse (Type A socket)

SD
32GB (Full size SD card socket)

NMEA 0183 baud rate
4800, 9600, 19200, & 38400 (via proprietary cable)

NMEA 0183 via RS232
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200

charting support
Navionics, CMAP, Insight, NV Charts on SD

What's in the Box:

• NSO evo3S MPU


• Power Cable


• RJ45-Yellow Round Ethernet adapter cable RJ45M / 5PinF


• NSO evo2 NMEA0183/Touch Monitor serial cable 2 m (6.5 ft) Eight core cable


• N2KEXT-6RD - 1.82 m (6-ft) NMEA 2000® cable


• N2K-PWR-RD - NMEA 2000® power cable. Includes power cable and 1 x T connector


• TR-120-KIT - Set of 1 male and 1 female NMEA 2000® terminators


• N2K-T-RD - Micro-C T-connector for connection of an additional network device x 2


• NSO evo2 Installation Kit


• Documentation
